Cars

1965 1300 'OT' PROTOTIPO



OT 1300 Prototipo Series 1 (1965)
Engine Position:
Rear
Number of Cylinders:
4
Valve Type:
dohc
Bore x Stroke:
86 x 55.5mm
Displacement:
1289.5cc
Compression Ratio:
10.5
Carburetion:
2 Weber 45 DCOE9
Max. Power:
147 bhp/8800 rpm
Max. Torque:
14.1 mkg/5600 rpm
Gearbox Speeds:
4, 5, 6
Final Drive Ratio:
5.4, 5.1, 4.9, 4.4, 3.9, 3.5
Wheel Front:
5.50 - 13
Wheel Rear:
6.00 - 13
Brakes Front:
disc
Brakes Rear:
disc
Wheelbase:
2015mm
Track Front:
1296mm
Track Rear:
1340mm
Length:
3830mm
Width:
1620mm
Height:
1040mm
Number of Seats:
2
Curb Weight:
655kg
Max. Speed:
245 km/h+
OT 1300 Prototipo Series 2 "World Champion" (1966)
Engine Position:
Rear
Number of Cylinders:
4
Valve Type:
dohc
Bore x Stroke:
86 x 55.5mm
Displacement:
1289.5cc
Compression Ratio:
10.5
Carburetion:
2 Weber 45 DCOE
Max. Power:
147 bhp/8800 rpm
Max. Torque:
14.1 mkg/5600 rpm
Gearbox Speeds:
5
Final Drive Ratio:
3.9
Wheel Front:
5.50 - 13
Wheel Rear:
6.00 - 13
Brakes Front:
disc
Brakes Rear:
disc
Wheelbase:
2015mm
Track Front:
1310mm
Track Rear:
1370mm
Length:
3830mm
Width:
1620mm
Height:
1222mm
Number of Seats:
2
Curb Weight:
670kg
Max. Speed:
245 km/h
OT 1300 Prototipo "World Champion" (1967)
Engine Position:
Rear
Number of Cylinders:
4
Valve Type:
dohc
Bore x Stroke:
86 x 55.5mm
Displacement:
1289cc
Compression Ratio:
11
Carburetion:
2 Weber 45 DCOE9
Max. Power:
157 bhp/8800 rpm
Max. Torque:
16.5 mkg/5700 rpm
Gearbox Speeds:
5, 6
Final Drive Ratio:
3.5
Wheel Front:
5.50 - 13
Wheel Rear:
6.50 - 13
Brakes Front:
disc
Brakes Rear:
disc
Wheelbase:
2015mm
Track Front:
1310mm
Track Rear:
1370mm
Length:
3830mm
Width:
1620mm
Height:
1222mm
Number of Seats:
2
Curb Weight:
655kg
Max. Speed:
258 km/h
OT 1300 Prototipo "World Champion" (1968)
Engine Position:
Rear
Number of Cylinders:
4
Valve Type:
dohc
Bore x Stroke:
86 x 55.5mm
Displacement:
1290cc
Compression Ratio:
11.5
Carburetion:
2 Weber 45 DCOE9
Max. Power:
157 bhp/8800 rpm
Max. Torque:
14.1 mkg/5600 rpm
Gearbox Speeds:
5
Final Drive Ratio:
5.4
Wheel Front:
5.50 - 13
Wheel Rear:
6.50 - 13
Brakes Front:
disc
Brakes Rear:
disc
Wheelbase:
2015mm
Track Front:
1375mm
Track Rear:
1375mm
Length:
3830mm
Width:
1620mm
Height:
1222mm
Number of Seats:
2
Curb Weight:
655kg
Max. Speed:
264 km/h
